Essentials
Product Collection
13th Generation Intel� Core� i5 Processors
Code Name
Products formerly Raptor Lake
Processor Number
i5-13600KF
CPU Specifications
Max Turbo Frequency
5.10 GHz
Performance-core Max Turbo Frequency
5.10 GHz
Efficient-core Max Turbo Frequency
3.90 GHz
Performance-core Base Frequency
3.50 GHz
Efficient-core Base Frequency
2.60 GHz
Cache
24 MB Intel� Smart Cache
Processor Base Power
125 W
Maximum Turbo Power
181 W
Memory Specifications
Max Memory Size (dependent on memory type)
128 GB
Memory Types
Up to DDR5 5600 MT/s
Up to DDR4 3200 MT/s
Max # of Memory Channels
2
Max Memory Bandwidth
89.6 GB/s
Expansion Options
Direct Media Interface (DMI) Revision
4.0
PCI Express Revision
5.0 and 4.0
PCI Express Configurations*
Up to 1x16+4, 2x8+4
Max # of PCI Express Lanes
20
Package Specifications
Advanced Technologies
Intel� Gaussian & Neural Accelerator
3.0
Intel� Thread Director
Yes
Intel� Deep Learning Boost (Intel� DL Boost)
Yes
Intel� Speed Shift Technology
Yes
Intel� Turbo Boost Max Technology 3.0*
No
Intel� Turbo Boost Technology*
2.0
Intel� Hyper-Threading Technology*
Yes
Instruction Set Extensions
Intel� SSE4.1, Intel� SSE4.2, Intel� AVX2
Enhanced Intel SpeedStep� Technology
Yes
Thermal Monitoring Technologies
Yes
Intel� Volume Management Device (VMD)
Yes
Security & Reliability
Intel� Standard Manageability (ISM)*
Yes
Intel� Control-Flow Enforcement Technology
Yes
Intel� AES New Instructions
Yes
Mode-based Execute Control (MBEC)
Yes
Intel� Virtualization Technology (VT-x)*
Yes
Intel� Virtualization Technology for Directed I/O (VT-d)*
Yes
Intel� VT-x with Extended Page Tables (EPT)*
Yes
