Features :

Stackable for Enthusiasts
With its endless stacking design, the Core X2 is in a class above the rest. Virtually limitless utility is possible; it offers an expandable system allowing enthusiasts to incorporate externally-modular upgrades. Stacked together, the chassis opens up space to expand the liquid cooling system, the storage solutions, or even create dual systems, thereby enabling a dedicated top/bottom set-up for pure cooling. When stacked, the maximum radiator length supported is 600mm on the front side.

Remarkable Expansion
Designed for high-end gaming system compatibility, the Core X2�s modular drive racks allow gamers to easily install up to six data storage devices, a dual expansion slot VGA of up to 480mm in length, and a tower CPU cooler as high as 230mm. Even with a high-wattage PSU stretching to 200mm in length, it still leaves plenty of space for cable management. Moreover, two 360mm radiators can be installed on top of the chassis, delivering superior cooling performance.

Great Ventilation
The Core X2�s unparalleled cooling ability offers fan brackets with various mounting points to support any type of gaming system that can be accommodated , including DIY/AIO liquid-cooling systems and air-cooling units. Two 120mm fan are pre-installed on the front and rear to reassure and guarantee the flow of aeration. The fan brackets can either be adjusted for 120mm, 140mm, or 200mm fans on the top panel, while there is room for 120mm and 140mm fans on the side panel.

Chambers Concept
Optimized for space management, the Core X2 is divided into two main chambers: the upper chamber is made for cooling performance and better efficiency, while the lower one is made for PSU and drive bays. Thanks to the removable 2.5"/3.5" drive device racks, there is plenty of flexibility to gain the maximum interior space when needed for advanced cooling performance or liquid systems build.

Fully Modular Design
A �3 +7" drive bay concept design for storage devices makes setting up the best storage solution on the market super easy and flexible. In addition, a customisable 5.25" & 3.5" drive bay feature enables users to freely interchange the 3.5" hard-drive cages to suit their particular needs.

Interchangeable Window and I/O Panel
Users can customize the chassis for the best viewing presentation with an interchangeable window and I/O panel design.

Tt LCS Certified is a Thermaltake exclusive certification applied to only products that pass the design and hardcore enthusiasts standards that a true LCS chassis should be held to. The Tt LCS certification was created so that we at Thermaltake can designate to all power users which chassis have been tested to be best compatible with extreme liquid cooling configurations to ensure you get the best performance from the best features and fitment.

Specifications :

• Item No.: CASE-CORE-X2
• Product Number: CA-1D7-00C1WN-00
• Case Type: mATX Cube
• Dimension (HxWxL): 46.5 x 32 x 54.1cm
• Side Panel Window: Yes
• Standard Cooling Fan:
  • Front: 1 X 120 X 120 X 25mm (1000rpm, 13dBA)
  • Rear: 1 X 120 X 120 X 25mm (1000rpm, 13dBA)
• DriveBays:
  • External: 3 x 5.25"
  • Internal: 4 x 3.5"/ 2.5", 3x 2.5"
• Expansion Slots: 5
• MB Support:
  • 6.7" x 6.7" (Mini-ITX)
  • 9.6" x 9.6" (MicroATX)
• I/O Ports:
  • USB2.0: Not Available
  • USB 3.0: 2
  • HD Audio: 1
• Fan Supports:
  • Front: 3 x 120mm or 2 x 140mm or 1 x 200mm
  • Rear: 1 x 120mm or 1 x 140mm
  • Top: 6 x 120mm or 2 x 140mm or 2 x 200mm
  • Bottom: 2 x 120mm
  • Side: 3 x 120mm (Left / Right)
• HDD: Not Available
• Radiator Supports:
  • Front: 1 x 120/240/360 mm or 1 x 140/280mm
  • Rear: 1 x 120mm or 1 x 140mm
  • Top: 1 X 120/240/360mm or 1 x 140/280mm
  • Bottom: 1 x 120/240mm
  • Side: 1 x 120/240/360mm (Left / Right)
• Clearance:
  • CPU Cooler Height: 23cm
  • Graphic Card Length: 33cm (with ODD rack)
  • ATX PSU Length: 22cm (Along with Bottom Fan)
