Model |
Core P3 TG Snow |
P/N |
CA-1G4-00M6WN-05 |
Case Type |
Mid Tower |
Dimension (H x W x D) |
12 x 333 x 470 mm (20.2 x 13.1 x 18.5 inch) |
Net Weight |
11.3 kg / 24.91 lb |
Side Panel |
5mm Tempered Glass x 1 |
Color |
Black |
Material |
SPCC |
Drive Bays -Accessible -Hidden |
2 x 3.5" or 3 x 2.5" (Outside the chassis) 2 x 3.5�� or
2.5�� (Inside the chassis) |
Expansion Slots |
8 |
Motherboards |
6.7� x 6.7� (Mini ITX), 9.6� x 9.6� (Micro ATX), 12� x 9.6�
(ATX) |
I/O Ports |
USB 3.0 x 2, USB 2.0 x 2, HD Audio x 1 |
PSU |
Standard PS2 PSU (optional) |
Fan Support |
Left Side: 3 x 120mm 3 x 140mm |
Radiator Support |
Left Side: 1 x 360mm 1 x 420mm |
Clearance |
CPU cooler height limitation: 180mm VGA length
limitation: 280mm (With Reservoir & Radiator) 450mm
(Without Reservoir & Radiator) PSU length limitation:
200mm |
