Model |
View 71 TG RGB Plus |
P/N |
CA-1I7-00F1WN-02 |
Case Type |
Full Tower |
Dimension (H x W x D) |
592 x 274 x 577 mm (23.3 x 10.8 x 22.7 inch) |
Net Weight |
19.3 kg / 42.55 lb |
Side Panel |
5mm Tempered Glass x 4 (Left & Right & Front & Top) |
Color |
Exterior & Interior : Black |
Material |
SPCC |
Cooling System |
Rear (exhaust) : 120 x 120 x 25 mm Riing Plus RGB fan
(500-1500rpm, 24.7dBA) Front (intake) : 120 x 120 x 25 mm
Riing Plus RGB fan (500-1500rpm, 24.7dBA) x3 |
Drive Bays |
2.5� x 4 or 3.5�x4 (HDD Rack) 2.5�x 6 or 3.5� x 3 |
Expansion Slots |
8+2 |
Motherboards |
6.7� x 6.7� (Mini ITX), 9.6� x 9.6� (Micro ATX), 12� x 9.6�
(ATX), 12� x 13�(E-ATX) |
I/O Port |
USB 3.0 x 2, USB 2.0 x 2, HD Audio x 1 |
PSU |
Standard PS2 PSU (optional) |
Fan Support |
Front: 3 x 120mm , 2 x 140mm Top: 3 x 120mm , 3 x
140mm Rear: 1 x 120mm, 1 x 140mm Bottom: 2 x
120mm |
Radiator Support |
Front: 1 x 360mm , 1 x 420mm Top: 1 x 360mm , 1 x
420mm Rear: 1 x 120mm, 1 x 140mm Right: 1 x 360mm,
1 x 420mm Bottom: 1 x 240mm |
Clearance |
CPU cooler height limitation: 190mm VGA length limitation:
310mm(With HDD Rack) 410mm(Without HDD Rack) PSU length
limitation: 220mm (Without Bottom Fan) |
