Part Number: CG2420
Category
Displays
 Computer Monitors
  EIZO
Buy Price GST Ex Buy Price GST Inc
$2,305.45 $2,536.00
Stock GST Rate
Call 10%
Description
Eizo 24.1inch ColorEdge IPS Monitor, 1920x1200, 10ms GtG, 1500:1, DVI, DisplayPort, HDMI, USB3 Hub, VESA, Built In Self Correction Sensor, ColorNavigator, 99% Adobe RGB, VESA

Detailed Description






Specifications :


Cabinet Color Black
Panel
Type IPS
Backlight Wide-Gamut LED
Size 24.1" / 61 cm (611 mm diagonal)
Native Resolution 1920 x 1200 (16:10 aspect ratio)
Viewable Image Size (H x V) 518.4 x 324 mm
Pixel Pitch 0.270 x 0.270 mm
Pixel Density 94ppi
Grayscale Tones DisplayPort, HDMI: 1024 tones (a palette of 65 thousand tones)
DVI: 256 tones (a palette of 65 thousand tones)
Display Colors DisplayPort, HDMI: 1.07 billion from a palette of 278 trillion
DVI: 16.77 million from a palette of 278 trillion
Viewing Angles (H / V, typical) 178�, 178�
Brightness (typical) 400 cd/m2
Recommended Brightness for Calibration 120 cd/m2 or less
Contrast Ratio (typical) 1500:1
Response Time (typical) 10 ms (Gray-to-gray)
Wide Gamut Coverage (typical) Adobe RGB: 99%, DCI-P3: 98%
Video Signals
Input Terminals DVI-D 24 pin (with HDCP), DisplayPort (with HDCP), HDMI (with HDCP, Deep Color)
Digital Scanning Frequency (H / V) DisplayPort, DVI: 26 - 78 kHz, 24 - 61 Hz (VGA Text: 69 - 71 Hz)

HDMI: 15 - 78 kHz, 24 - 61 Hz (VGA Text: 69 - 71 Hz)
USB
Function 1 ports for monitor control
3-port USB hub
Standard USB 3.0
Power
Power Requirements AC 100 - 240 V, 50 / 60 Hz
Maximum Power Consumption 79W
Typical Power Consumption 20W
Power Save Mode Less than 0.7W
Standby Mode Less than 0.6W
Power Management Power Save (DisplayPort Version 1.1a, and DVI DMPM)
Self-Calibration Yes
Features & Functions
Brightness Stabilization Yes
Digital Uniformity Equalizer Yes
Preset Modes Color Mode (Custom, Adobe RGB, sRGB, Calibration)
OSD Languages English, German, French, Italian, Japanese, Simplified Chinese, Spanish, Swedish, Traditional Chinese
Others Color Adjustment (Brightness, Temperature, Gamma, Color Gamut, Hue, Saturation, Clipping, Gain, Independent 6-Color Control, Reset), Picture Expansion (Auto, Full Screen, Aspect Ratio, Dot by Dot), Input Color Format, Input Range, Noise Reduction, Auto Iuput Detection, Menu Rotation, USB CHARGE Port, Power Save, Indicatior, Beep, Input Skip, Mode Skip, Signal Info, Monitor Info, Key Lock, DP Power Save, DUE Priority, Signal Format, Monitor Reset
Physical Specifications
Dimensions (Landscape, W x H x D) 554.4 x 396 - 551 x 245 mm
Dimensions (Portrait, W x H x D) 362 x 565.4 - 647.2 x 245 mm
Dimensions (Without Stand, W x H x D) 554.4 x 362 x 64 mm
Net Weight 7.8 kg / 17.2 lbs
Dimensions (Landscape with Hood, W x H x D) 572.4 x 405 - 560 x 336 mm
Net Weight (Without Stand) 5.0 kg / 11.0 lbs
Net Weight (With Hood) 8.5 kg / 18.7 lbs
Height Adjustment Range 155 mm
Tilt 35� Up, 5� Down
Swivel 344�
Pivot 90�
Hole Spacing (VESA Standard) 100 x 100 mm
Environmental Requirements
Operating Temperature 0 - 35 �C
Operating Humidity (R.H., non condensing) 20 - 80 %
Certifications & Standards (Please contact EIZO for the latest information.) CB, CE, TUV/GS, cTUVus, FCC-B, Canadian ICES-003-B, VCCI-B, TUV/Ergonomics, TUV/Color Accuracy (Quick Stability), RCM, RoHS, WEEE, EAC, Energy labelling of televisions
Supplied Accessories (May vary by country. Please contact EIZO for details.) AC power cord, signal cables (DVI-D - DVI-D, Mini DisplayPort - DisplayPort), USB cable, Setup guide, EIZO LCD Utility Disk (ColorNavigator software, PDF user's manual), Adjustment certificate, ScreenCleaner, Monitor hood, Mounting screw, Quick reference, Warranty card
Warranty Five Years 2 5
Zero bright sub-pixels for six months from date of purchase








Warranty Details
Warranty Period : 5 Years
* Stock amount is quantity held by Award One Technology and its suppliers
